Razor Wire

For applications which require the most effective security measures, we offers a variety of toppings which for the deterrence of intruders. Choose from concertina razor wire and flat-wrap razor barb as an addition to the majority of our fencing systems or as an independent barrier on rooftops and walls.



Please note:
Razor wire warning signs are required by the Consumer Protection Act and must be illuminated at night. We can supply these on request.



Features
Razor barb available in single strand, concertina or flat-wrapped



Applications
High security
Anti-intruder

)77[I1FBO7`I%(VJ[S91FIC
SKFU7_8B]9F7A8PY[9_O0~I

Technical Specification

Product Blade Style Blade Thickness Wire Diam Barb Length Barb Width Barb Spacing
BT-10 0.5mm 2.5mm 10mm 13mm 26mm
BT-12 0.5mm 2.5mm 12mm 15mm 26mm
BT-18 0.5mm 2.5mm 18mm 15mm 33mm
BT-22 0.5mm 2.5mm 22mm 15mm 34mm
BT-28 0.5mm 2.5mm 28mm 15mm 45mm
BT-60 0.6mm 2.5mm 60mm 32mm 100mm
BT-65 0.6mm 2.5mm 65mm 21mm 100mm

Note:
Standard products are shown in the tables above, special specifications available on request.
Standard materials are either galvanized or stainless steel.

Our core wire made from high tensile galvanized steel wire (1500MPA),make the razor wire more rigid and difficult to cut.

Razor Wire Concertina Specifications
Outside Diameter No. of Spirals No. of Clips Recommended Stretch Length Notes
300mm 33   8-10M Unclipped
450mm 33   12-15M Unclipped
600mm 33   12-15M Unclipped
300mm 33 3 4M Clipped
450mm 54 3 8-10M Clipped
610mm 54 3 10-12M Clipped
730mm 54 3 15-20M Clipped
730mm 54 5 10-12M Clipped
980mm 54 5 10-15M Clipped
