Filter Mesh

MESH COUNT WIRE DIAMETER NOMINAL
PER INCH INCHES MICRON
WARP x SHUTE WARP x SHUTE RETENTION
PLAIN DUTCH WEAVE
12 x 64 .023 x .0165 180
24 x 110 .015 x .0105 115
30 x 150 .009 x .007 95
30 x 160 .009 x .007 90
40 x 200 .007 x .0055 75
50 x 250 .0055 x .0045 60
TWILLED DUTCH WEAVE
20 x 250 .0036 x .008 87
30 x 250 .010 x .008 70
80 x 700 .004 x .003 30-35
165 x 800 .0029 x .0020 25
165 x 1200 .0028 x .0016 19
165 x 1400 .0028 x .0016 14
200 x 600 .0026 x .0018 26
200 x 900 .0020 x .0014 23
200 x 1400 .0028 x .0016 10
250 x 1370 .0022 x .0016 8
250 x 1400 .0022 x .0016 8
250 x 1620 .0022 x .0015 7
325 x 1370 .0014 x .0012 7
325 x 1700 .0014 x .0012 6
325 x 1900 .0014 x .0011 5
325 x 2300 .0014 x .0011 5
325 x 2800 .0014 x .0010 4
325 x 2400 .0012 x .0009 4
400 x 2800 .0011 x .00078 2

PLAIN DUTCH WEAVE
Plain Dutch Weave is primarily used as a filter cloth. The openings slant diagonally through the cloth and cannot be seen by looking directly at the cloth. This weave has a coarser mesh and wire in the warp direction and a finer mesh and wire in the shute direction, giving a very compact, firm mesh with great strength.

z_plain_dutch_weave2

TWILLED DUTCH WEAVE

Twilled Dutch Weave offers higher strength than regular Dutch weaves. It packs even more wires in a given area. Generally, this weave has finer mesh counts and lower flow than regular Dutch weaves and can be made to filter particles as fine as 2 microns in diameter.

z_twilled_dutch_weave2
