Nylofor 3-M

Cost effective
PVC coating ensures long lifetime
Faster installation
Available as a complete system

Benefits

Excellent price/quality rate
The extra long panels (3 meters) in combination with the Quixolid posts without accessories, guarantee more than a double price advantage preserving quality and rigidity.

Extra long lifetime
The coating technology is state of the art and assures an extra long life.
A special layer is applied after galvanisation to ensure total adhesion of the PVC top coat.

Fast installation
Due to the 3 meter long panels, the fence is very fast to install.

High rigidity
Heavy welded mesh panels with rectangular meshes and horizontal curves guarantee a high level of rigidity.

Complete system
The system consists of panels in various heights and can be installed on multiple post systems.
A wide assortment of innovative swing and sliding gates is completing the fence.

Ideal for
Long distance fencing

Mesh size: 200x50mm
Horizontal and vertical wire diameter: 5mm
Finish: galvanized then pvc coating.
Color:  green RAL6005 ,black RAL9005 and other color.
The panels have vertical barbs of 30 mm on one side (top or at bottom).
Fence height Dimensions panels No. of reinforcements Post length
(mm) W x H (mm) per panel (mm)
1230 3000 x 1230 2 1700
1530 3000 x 1530 3 2000
1730 3000x1730 3 2200
1930 3000x1930 3 2400
2030 3000x2030 4 2600
2430 3000x2430 4 3200
